Solar Charge Controller 96v-60a With LCD Display

Manufacturer and Supplier of Solar Charge Controller 96v-60a With LCD Display

kavita solar Offer a wide range of Electronic SPV Charge Controllers / Regulators with standard and custom built versions. The Standard model generally conforms to MNRE specifications.

Electrical Specification:

For Solar Charge Controller 96V-60A

Load disconnect battery voltage 88 ± 0.2 volts or as required

Load reconnect battery voltage 98 ± 0.2 volts or as required

Constant Charging Voltage 114 ± 0.2 volts or as required

Idle current consumption Less than 5ma

Key Features :

• Affordable

• Safe, efficient and reliable

• Easy to install

• PWM Charging

• Temperature Compensation

• As per MNRE Specification

• Micro Controller Based High efficiency electronics

General Specifications and Features:-

Housing material : MS

Provisions

Fuse

DIGITAL DISPLAY

LCD indications

Battery charging in process

Battery Charged (Charging disconnect)

Battery deep discharge (Load disconnect)

Battery Voltage

Solar Voltage

Charging Current

LED indications

Battery charging in process

Battery Charged (Charging disconnect)

Battery deep discharge (Load disconnect)

Fuse Blown

SOLAR REVERSE

BATTERY REVERSE

Protection options :

Battery Reverse polarity

Battery deep discharge

Battery Overcharge

100% short circuit

Surge/lightning
